Automated Billing (Autobill)

Important

Before running Autobill, ensure:

  • A provider and PBX server are configured and connected.

  • Packages and tariffs are set up and linked to client products.

  • CDRs are being collected from the PBX.

  • The WHMCS daily CRON is scheduled.

  • The autobill CRON is scheduled to run before the WHMCS daily CRON.

CDR Processing & Automated Billing Configuration

The Autobill system processes call detail records (CDRs) and generates automated billing for VoIP services. This automated process ensures accurate and timely billing for all VoIP usage.


Autobill Dashboard

Overview

Autobill is a critical component that processes CDRs from your PBX servers and generates billing records in WHMCS. The system runs as a scheduled CRON job and integrates seamlessly with WHMCS billing cycles.

Key Features:

  • Automated CDR processing

  • Real-time billing generation

  • Multi-server support

  • Flexible scheduling

  • Debug and testing capabilities

  • Special Number Billing support

In ictVoIP Billing v1.5.0, Autobill remains the engine that turns rated CDRs into billable usage. FusionPBX now offers three billing script options:

Autobill v2 (autobill_v2.php)

The enhanced browser-based UI with real-time statistics, progress indicators, and color-coded debug output. Creates separate invoices for each FusionPBX service per client. Recommended for clients who prefer itemized billing.

Autobill v3 (autobill_v3.php) - New in v1.5.0

Consolidated billing script that combines multiple FusionPBX services per client into a single invoice. Supports International, National, and Special Rate call types. Provides dynamic admin email notifications that scale to any number of services. Recommended for clients who want simplified billing with one invoice per billing period for all VoIP services.

Autobill v1 (autobill.php)

The original headless script for CRON execution. Still supported for legacy deployments.

Choosing Between v2 and v3:

  • Use v2 if clients need separate invoices for each service (e.g., different cost centers)

  • Use v3 if clients want consolidated billing (all VoIP services on one invoice)

  • Both support the same call types and billing features

  • Both use identical underlying billing logic

Version Comparison

Key Differences from v1

Feature

autobill.php (v1)

autobill_v2.php

autobill_v3.php

UI

Plain text

Modern styled UI

Modern styled UI

Real-time updates

No

Yes

Yes

Progress bar

No

Yes

Yes

Statistics dashboard

No

Yes

Enhanced

Icons/Emojis

No

Yes

Yes

Responsive layout

No

Yes

Yes

Time tracking

No

Yes

Yes

Multi-module support

FusionPBX only

FusionPBX only

FusionPBX + VoIP + VoIPFax

Consolidated billing

No

No

Yes

Other supported server modules (for example, Vodia or custom integrations) continue to ship with their own autobill.php-style scripts, which are typically used only for headless CRON execution.

Autobill v3 Consolidated Invoicing

Autobill v3 processes every active FusionPBX service for a client and combines the rated CDR charges into a single WHMCS invoice.

  • It scans all FusionPBX services due on the billing run date.

  • It accumulates charges across services while keeping separate invoice line items for International, National, and Special Rate calls.

  • Special-rate calls are grouped by matching pattern, and regular tariff/custom-rate calls are grouped by service.

  • Once all services for a client are processed, v3 creates one invoice with the consolidated line items instead of one invoice per service.

  • A single email notification is generated per client, summarising the consolidated totals.

This is the recommended autobill mode for clients who prefer one invoice per billing period covering all VoIP services.

CRON Configuration

Note

The Autobill script must run before the WHMCS daily CRON job to ensure proper billing processing.

Scheduling Requirements:

Important

AlmaLinux 9 / systemd Timezone Configuration

On AlmaLinux 9 / systemd-based systems, cron jobs may default to UTC even when:

  • Server time is correct

  • PHP-FPM timezone is correct

  • WHMCS timezone is correctly configured

WHMCS automation relies on the execution time of cron.php, not just internal settings.

Solutions:

  1. Per-CRON Timezone (Recommended): Specify TZ= explicitly in each WHMCS cron job to avoid automation running early or late after server migrations.

  2. System-Wide PHP INI: Update the system PHP INI configuration to set date.timezone system-wide if this option is available on your hosting environment.

Recommended Schedule:

WHMCS Daily CRON: 1:00 AM
Autobill CRON: 12:55 AM (5 minutes before)

Alternative Schedule:
WHMCS Daily CRON: 2:00 AM
Autobill CRON: 12:45 AM (75 minutes before)

CRON Entry Format:

Replace MYMODULE with your installed server module and America/Toronto with your timezone:

# FusionPBX - Autobill v2 (separate invoices per service)
55 00 * * * TZ=America/Toronto GET https://www.mywhmcsserver.com/modules/servers/fusionpbx/autobill_v2.php?runfrom=cron

# FusionPBX - Autobill v3 (consolidated invoices - NEW in v1.5.0)
55 00 * * * TZ=America/Toronto GET https://www.mywhmcsserver.com/modules/servers/fusionpbx/autobill_v3.php?runfrom=cron

# Alternative format with more time
45 00 * * * TZ=America/Toronto GET https://www.mywhmcsserver.com/modules/servers/fusionpbx/autobill_v3.php?runfrom=cron

# PHP CLI format (alternative)
55 00 * * * TZ=America/Toronto /usr/bin/php -q /home/USERNAME/public_html/whmcs/modules/servers/fusionpbx/autobill_v3.php runfrom=cron

CRON Parameters:

  • TZ=America/Toronto - Explicit timezone (required for AlmaLinux 9 / systemd)

  • 55 00 - Time (12:55 AM in specified timezone)

  • * * * - Daily execution

  • GET - HTTP method (or /usr/bin/php -q for CLI)

  • runfrom=cron - Execution parameter

FusionPBX Script Selection:

  • autobill_v2.php - Separate invoices for each service (itemized billing)

  • autobill_v3.php - Consolidated invoices (all services combined per client)

Other Server Module Examples:

  • Vodia: vodia/autobill.php

  • Custom: custom/autobill.php

Note

For FusionPBX deployments, choose between v2 (separate invoices) or v3 (consolidated invoices) based on your billing requirements. Both scripts use the same underlying billing logic and support all call types (International, National, Special Rates). See the CRON reference documentation at https://ictvoip.ca/docs/cron-reference.html for detailed setup instructions.

WHMCS Automation and Prorata Behavior

autobill_v2.php and autobill_v3.php follow WHMCS billing dates rather than inventing their own cycle. The service Next Due Date, WHMCS Automation Settings, and product prorata settings all influence when usage invoices are created and what date range they represent.

Automation Settings

  • Monthly invoice generation lead time: CreateInvoiceDaysBeforeMonthly is used first for Monthly services. If blank or 0, the script falls back to CreateInvoiceDaysBefore.

  • Invoice creation day: If WHMCS generates invoices in advance, autobill_v2.php selects services whose Next Due Date matches the automation target date.

  • Invoice due date: Usage invoices use the same due date target expected by WHMCS automation.

Prorata Settings

WHMCS product settings such as Prorata Billing, Prorata Date, and Charge Next Month affect the service billing cycle that WHMCS establishes. Autobill follows the dates WHMCS assigns to the service.

  • Prorata Billing: Determines whether WHMCS aligns the service onto a calendar billing point.

  • Prorata Date: Controls the target calendar day for the service cycle.

  • Charge Next Month: Affects initial order/prorata behavior and can change the first invoice outcome depending on signup date.

First Cycle vs Subsequent Cycles

  • First cycle: The CDR class can use the service Date Registered (regdate) as the start of the first usage billing period when no prior non-cancelled WHMCS Hosting invoice item exists for that service.

  • Subsequent cycles: Once WHMCS has created the normal Hosting invoice item for the service, later autobill runs use the standard rolling cycle for Monthly billing.

Desired Outcome Examples

  • Invoice on the 15th, due on the 1st: If CreateInvoiceDaysBeforeMonthly = 15 and the service Next Due Date is the 1st, autobill creates the usage invoice on the 15th of the prior month and sets the due date to the 1st.

  • Same-day invoicing: If both CreateInvoiceDaysBeforeMonthly and CreateInvoiceDaysBefore are 0, the script behaves as same-day billing and only targets services due today.

Operational Notes

  • WHMCS daily cron matters: WHMCS daily automation creates the standard service renewal invoice item that marks the service as having entered its normal cycle.

  • Payment progression matters: After the renewal invoice is paid, WHMCS typically advances the service Next Due Date; once advanced, the same cycle should no longer be selected by autobill.

  • Best practice: Configure WHMCS Automation Settings and product prorata settings together, then verify the resulting service Next Due Date.

Manual Testing

Browser Testing:

Both Autobill v2 and v3 provide a custom browser UI when opened directly without a CRON trigger. The page shows real-time progress, client and invoice counters, and colour-coded log output. Use this to test and debug a billing run before enabling the CRON.

Test your Autobill installation by accessing the script directly in your browser:

# FusionPBX (Autobill v2 - separate invoices)
URL: https://www.mywhmcsserver.com/modules/servers/fusionpbx/autobill_v2.php?runfrom=cron
Method: GET
Authentication: Required

# FusionPBX (Autobill v3 - consolidated invoices)
URL: https://www.mywhmcsserver.com/modules/servers/fusionpbx/autobill_v3.php?runfrom=cron
Method: GET
Authentication: Required

# Other modules (generic example)
URL: https://www.mywhmcsserver.com/modules/servers/MYMODULE/autobill.php?runfrom=cron
Method: GET
Authentication: Required

Test Configuration:

Before testing, ensure proper configuration:

  1. Set Test Date - Configure client’s next due date to current date

  2. Enable Debug - Activate debug mode for detailed output

  3. Check Permissions - Verify script access permissions

  4. Review Logs - Monitor execution logs

Test Process:

  1. Access Script - Open autobill URL in browser

  2. Monitor Output - Watch for processing results

  3. Review Results - Check billing calculations

  4. Verify Billing - Confirm invoice generation

Debug Configuration

Enable Debug Mode:

Activate debug mode to view detailed processing information:

  1. Navigate to ictVoIP Billing → Billing Management

  2. Enable CDR Autobill Debug

  3. Run manual autobill execution

  4. Review debug output

Debug Information:

Debug mode provides detailed information including: * CDR processing status * Rate calculations * Billing summaries * Error messages * Processing timestamps

Debug Output Example:

[DEBUG] Starting Autobill Process
[DEBUG] Processing Server: FusionPBX-01
[DEBUG] Found 150 CDR records
[DEBUG] Applied rates to 145 records
[DEBUG] Generated billing for 5 clients
[DEBUG] Process completed successfully

Billing Integration

WHMCS Integration:

Autobill integrates with WHMCS billing cycles:

  • Invoice Generation - Creates invoices for processed CDRs

  • Billing Date Management - Updates next due dates

  • Product Billing - Processes monthly/annual billing

  • Invoice Delivery - Sends invoices to clients

Billing Cycle Process:

  1. Autobill Execution - Process CDRs and calculate charges

  2. WHMCS Daily CRON - Generate invoices and update billing dates

  3. Invoice Delivery - Send invoices to clients

  4. Payment Processing - Handle payment collection

Note

  • Autobill does not increment product next billing dates.

  • WHMCS daily CRON handles billing date updates.

  • Monthly invoices are generated after Autobill processing.

  • Billing dates are updated during WHMCS daily CRON execution.

Performance Optimization

New in version 1.4.0-Beta.11: Tariff lookup performance optimization (159x faster)

Processing Time Considerations:

  • Small Installations - 5 minutes before WHMCS CRON

  • Medium Installations - 15 minutes before WHMCS CRON

  • Large Installations - 30+ minutes before WHMCS CRON

Factors Affecting Processing Time:

  • Number of Servers - More servers = longer processing

  • CDR Volume - Higher call volume = longer processing

  • Server Performance - CPU and memory limitations

  • Network Latency - API response times

  • Tariff Table Size - Larger tariff tables require more lookups

Tariff Lookup Optimization (v1.4.0-Beta.11+):

The FusionPBX module includes an optimized tariff lookup system that dramatically improves processing speed for large CDR volumes:

  • In-Memory Cache - Tariff tables under 500,000 entries are loaded into memory once

  • Zero DB Queries Per CDR - After initial cache load, lookups are pure in-memory operations

  • Automatic Strategy Selection - System chooses optimal approach based on table size

  • Verified Results - Billing amounts remain identical to previous versions

Performance Benchmarks:

Metric

Before (v1.4.0-Beta.10)

After (v1.4.0-Beta.11)

Processing Time (2,400 CDRs)

636 seconds (~10.6 min)

4 seconds

DB Queries per CDR

Up to 10 (recursive)

0 (cached lookup)

Memory Usage

Low

~50MB for 322K tariff entries

PHP Memory Requirements:

For optimal tariff cache performance, ensure your PHP configuration meets these requirements:

; Recommended PHP settings for large tariff tables
memory_limit = 8096M
max_execution_time = 300

Optimization Tips:

  • Monitor Processing Time - Track execution duration

  • Adjust Scheduling - Increase time buffer if needed

  • Server Optimization - Improve server performance

  • CDR Cleanup - Regular CDR database maintenance

  • Memory Allocation - Ensure sufficient PHP memory for tariff caching

Special Number Billing

Autobill supports Special Number Billing for products configured with custom rate rules. When enabled, special rate patterns are processed before standard tariff billing.

How It Works:

  1. CDRs are checked against special rate patterns first

  2. Matching CDRs are billed using the configured special rate rules

  3. Non-matching CDRs are skipped (not billed) when special rates are enabled

  4. Special rate calls are grouped by pattern on invoices

Invoice Display:

Special Rate Calls (29/12/2025 to 29/01/2026)
[OUTBOUND] 1300* (flat_per_call): 4 calls, 11 min, $1.40
[OUTBOUND] 1800* (flat_per_call): 1 calls, 5.7 min, $0.35

For detailed configuration, see FusionPBX Configuration Guide under “Special Number Billing”.

Error Handling

Common Errors:

  • Connection Timeout - Server unavailable

  • Authentication Failed - Invalid credentials

  • Permission Denied - File access issues

  • Database Errors - CDR processing issues

Error Resolution:

  1. Check Server Status - Verify PBX server availability

  2. Review Credentials - Confirm API authentication

  3. Check Permissions - Verify file and database access

  4. Monitor Logs - Review error logs for details

Log Monitoring:

Monitor autobill logs for issues:

# Check autobill logs
tail -f /var/log/autobill.log

# Check WHMCS logs
tail -f /var/log/whmcs.log

# Check system logs
tail -f /var/log/syslog

Security Considerations

Access Control:

  • HTTPS Required - Always use secure connections

  • Authentication - Implement proper access controls

  • IP Restrictions - Limit access to trusted IPs

  • Log Monitoring - Monitor access attempts

Best Practices:

  • Secure Credentials - Use strong API passwords

  • Regular Updates - Keep scripts updated

  • Backup Configuration - Maintain backup copies

  • Audit Logs - Review access logs regularly

Troubleshooting

Common Issues:

  • Script Not Executing - Check CRON configuration

  • No CDRs Processed - Verify server connectivity

  • Billing Errors - Check rate configuration

  • Performance Issues - Monitor processing time

Debug Steps:

  1. Check CRON Status - Verify CRON job execution

  2. Test Manual Execution - Run script manually

  3. Review Error Logs - Check for error messages

  4. Verify Configuration - Confirm settings

Support Information:

For autobill issues, provide: * CRON configuration * Error messages and logs * Server module details * Processing time information

See also

Next Steps

After configuring autobill:

  1. Test Execution - Run manual tests

  2. Monitor Performance - Track processing times

  3. Review Billing - Verify invoice generation

  4. Production Deployment - Enable automated execution
